Why Rhinozak?

Maximum Safety

Armored cabin and reinforced structure provide full protection against high-pressure blasts, keeping operators secure in all conditions.

Modular Design

Customizable with different equipment and modules to meet diverse mission requirements.

Powerful Blasting Capability

Advanced detonation system ensures controlled and effective mine clearance across large areas.

Rapid Operation

Delivers fast and efficient clearance, saving critical time in high-risk environments.

Mobility on All Terrains

Engineered for maneuverability on rough, muddy, or rocky landscapes without compromising stability.

Military & Humanitarian Use

Equally effective for military missions and humanitarian demining operations to ensure civilian safety.

Transportability Suitable for container, trailer, C-130 aircraft transport

Contact for more.

Rhinozak Mine Blasting Vehicle

Built to deliver unmatched safety and performance, the Rhinozak is designed for both military operations and humanitarian missions. With its rugged design and advanced technology, it ensures efficient and reliable mine clearance in the toughest environments.

Maximum Protection

All-Terrain Mobility

Fast & Efficient

High Blasting Power

Modular Flexibility

Dual Purpose

Contact

TECHNICAL SPECIFICATIONS

Total length (with attachment) 6700MM
Total width (vehicle) 1775MM
Total width (attachment) 2550MM
Working width 1900MM
Track track width 1725MM
HeightTotal weight 12500KG

PALLET SPECIFICATIONS

Ground pressure 0.63 kg/cm2
Ground chassis clearance 275 mm
Maximum gradeability 60%
Maximum sliding slope 40%
Maximum travel speed 4 km/h
Operating speed 0.5-1 km/h
Track carrying capacity 14,000 kg

ARMOR SPECIFICATIONS

Body 4 mm Weldox_Strenks
Chassis 10 mm Armox 500T
Attachment Frame 10 mm Armox 500T 40%
Arms 6-10-20 mm Welldox 700 Strenks 700-Hardox 450
Attachment Interior 10 mm Armox 500T

ATTACHMENTS SPECIFICATIONS

Quick coupler type Quick Coupler
Digging Attachments Tiller/Chain
Digging depth 0-25 cm
Digging depth control Automatic skid or sensor

SPECIFICATIONS

Weight 9,750 kg
Dimensions 6.5 m × 2.85 m × 2.4 m (with attachments)
Armor coated with Armox 500T; resistant to 8 kg TNT
Maximum Speed 4 km/h
Cleaning Area 1 km × 1.7 m/h or 950–1,900 m²/h
Cleaning Depth 25cm
Slope Capability 60% vertical, 40% lateral
Control Range 500 m–5 km
Image and Data System HD video, wireless transmission, sensor-assisted; 360° camera, Operator display
Engine Diesel, ~300 hp
Transportability Suitable for container, trailer, C-130 aircraft transport

ENGINE SPECIFICATIONS

Engine Type: Deutz, 6 Cylinders
Displacement: 7200 cc
Maximum Power: 200 kW at 2300 rpm
Maximum Torque: 1050 Nm at 1500 rpm
Fuel Consumption: 25-35 L/h
Fuel Capacity: 280 L
Fuel Type: Diesel
Full Tank and Run Time: 10 h
Cooling System: Water-Cooled
Emissions: EU IIIA, US T3
